Beschrijving
Nieuw in de doos. Wij zijn AVM merkdealer, volledige garantie. We verkopen onze overstock met hoge korting, sla je slag! Maar 1 model voor deze prijs!
Normale prijs: € 5.990,- nu voor € 3.990,-!!
Preamplifier
Distortion factor (MP 3.3) < 0.001 %
Frequency response at -3dB (MP 3.3) < 0 Hz to > 100 kHz
Frequency response at -3dB (MP 5.3) < 5 Hz to > 100 kHz
Signal-to-noise ratio > 100 dB
Crosstalk attenuation (channels) > 100 dB
Output impedance (RCA) 47
Output impedance (XLR) 94
Output headroom PRE OUT (1% THD) 8.5 V
Output level LINE OUT 2.5 V
CD-Player
Playable formats CD Audio, CDR (according to Red-Book standard)
Frequency response CD < 20 – 20 kHz
Network
LAN connection (hot plug capable) 100 Mbit/s
Supported WLAN/WiFi standards 2.4/ 5GHz/ 802.11a/b/g/n/ac
Number of antennas 2
WPS yes
Streaming
Max. sampling rates DSD256, 32 Bit/384 kHz PCM
Streaming services AirPlay, Qobuz, Roon, Spotify, TIDAL Connect MAX, HighResAudio
Supported file formats WAV, MP3, WM, AAC, FLAC, ALAC, DSD, Ogg, AIFF
Bluetooth
Bluetooth standard 5.0
Supported Bluetooth profiles AVRCP 1.5, AD2P
USB Input (Rear)
USB standard USB 2.0
Max. current 500 mA
Supported formats FAT16, FAT32, NTFS
WARNING: The USB input is exclusively for hard drives and USB sticks!
Digital inputs (S/P-DIF/Coaxial)
Max. sampling/bit rate (OPTO) 96 kHz / 24 Bit
Max. sampling/bit rate (COAX) 192 kHz / 24 Bit
Min. signal level [Vpp] at 192kHz (COAX) > 150 mVpp
Input impedance (COAX) 75
Deemphasis (OPTO, COAX) Yes, automatic
Max. sampling/bit rate (ARC) 192 kHz / 24 Bit
Input impedance 75
NOTE: When using digital inputs
Digital outputs (S/P-DIF / Coaxial)
Max. sampling/bit rate (OPTO) 96 kHz / 24 Bit
Max. sampling/bit rate (COAX) 192 kHz / 24 Bit
Output impedance (COAX) 75 ?
NOTE: When using digital outputs
Control
Trigger input 5 – 20V
Trigger output (2x) 12V (sequentially switched)
NOTE: The second trigger-out is delayed from the first trigger-out to protect against excessive current surges. Please use a standard 3.5mm mono jack cable for the trigger connections.
Power connection
Power supply 100V-240V / 50Hz-60Hz
Power consumption standby < 0.5 Watt
Power consumption network standby < 2 Watt
Power consumption (typical) < 18 Watt
Power consumption (maximum) 30 Watt
Fuse used T 1A
General
Weight 7.5 kg
Dimensions (WxHxD) 430 x 122 x 330mm
Warranty 2 years + 2 years with online registration
(Warranty periods may vary in other distribution countries)
